Diverter Pulley

Size	Groove Nos	Groove Size	Pitch	Bearing	Shaft
150	5	8	12	6209-2RS	45
150	6	8	12	6209-2RS	45
150	7	8	12	6209-2RS	45
180	4	8	12	6210-2RS	50
180	5	8	12	6210-2RS	50
180	6	8	12	6210-2RS	50
200	3	8	12	6210-2RS	50
200	3	13	19	6210-2RS	50
200	4	8	12	6210-2RS	50
200	5	6.5	12	6210-2RS	50
200	6	6.5	12	6210-2RS	50
200	6	10	17	6210-2RS	50
200	8	6.5	12	6210-2RS	50
240	4	6.5	12	6210-2RS	50
240	4	8	12	6210-2RS	50
240	4	10	17	6210-2RS	50
240	4	13	19	6210-2RS	50
240	5	6.5	12	6210-2RS	50
240	5	8	12	6210-2RS	50
240	5	10	17	6210-2RS	50
240	5	13	19	6210-2RS	50
250	3	8	12	6209-2RS	45
320	3	13	19	6210-2RS	50
320	4	8	12	6210-2RS	50
320	4	10	17	6210-2RS	50
320	4	13	19	6210-2RS	50
320	5	8	12	6210-2RS	50
320	5	10	17	6210-2RS	50
320	5	13	19	6210-2RS	50
320	6	8	12	6210-2RS	50
320	6	10	17	6210-2RS	50
320	7	8	12	6210-2RS	50
320	8	8	12	6210-2RS	50
320	10	8	12	6210-2RS	50
320	12	8	12	6210-2RS	50
360	4	10	17	6210-2RS	50
360	5	10	17	6210-2RS	50
360	6	10	17	6210-2RS	50
400	3	10	17	6210-2RS	50
400	3	13	19	6210-2RS	50
400	4	8	12	6210-2RS	50
400	4	10	17	6210-2RS	50
400	4	13	19	6210-2RS	50
510	4	8	12	6210-2RS	50
510	4	10	12	6210-2RS	50
525	4	10	17	6211-2RS	55
525	5	10	17	6211-2RS	55
525	6	10	17	6211-2RS	55

Governor Pulley

Size	Groove Nos	Groove Size
200	1	6 & 8
300	1	8
300	2	6 & 8

Traction Sheave

Pulley Description	PCD	Wire Dia	Groove
TRACTION SHEAVE(160PCDxØ6.5x4G)	160	6.5	4
TRACTION SHEAVE(160PCDxØ6.5x7G)	160	6.5	7
TRACTION SHEAVE(200PCDxØ8x4G)	200	8	4
TRACTION SHEAVE(240XØ6.5X8G)	240	6.5	8
TRACTION SHEAVE(240PCDXØ6.5X10G)	240	6.5	10
TRACTION SHEAVE(240PCDxØ8x4G)	240	8	4
TRACTION SHEAVE(320PCDXØ8X4G)	320	8	4
TRACTION SHEAVE(320PCDXØ8X6G)	320	8	6
TRACTION SHEAVE(320PCDxØ8x8G)	320	8	8
TRACTION SHEAVE(320PCDxØ8X12G)	320	8	12
TRACTION SHEAVE(400PCDXØ8X4G)	400	8	4

Belt Pulley

Pulley Description
2G Diverter Sheave
3G Diverter Sheave
Belt 4G Diverter Sheave
5G Diverter Sheave
V- Belt Pulley A-type
V- V- Belt Pulley B-type
Timing Belt Pulley

Request for inquiry

Get in Touch

Quick links

Follow Us

© 2024 www.bajarangindustries.com

Groove Table

Size	Groove Nos	Groove Size (mm)	Pitch (mm)	Bearing	Shaft (mm)
150mm	5	8	12	6209-2RS	45
	6	8	12	6209-2RS	45
	7	8	12	6209-2RS	45

Groove Table - 180mm

Size	Groove Nos	Groove Size (mm)	Pitch (mm)	Bearing	Shaft (mm)
180mm	4	8	12	6210-2RS	50
	5	8	12	6210-2RS	50
	6	8	12	6210-2RS	50

Groove Table - 200mm

Size	Groove Nos	Groove Size (mm)	Pitch (mm)	Bearing	Shaft (mm)
200mm	3	8	12	6210-2RS	50
	3	13	19	6210-2RS	50
	4	8	12	6210-2RS	50
	5	6.5	12	6210-2RS	50
	6	6.5	12	6210-2RS	50
	6	10	17	6210-2RS	50
	8	6.5	12	6210-2RS	50

240mm Part Table

240mm Part Details
Size	Qty	Length	Width	Part No.	Weight
240mm	4	6.5	12	6210-2RS	50
240mm	4	8	12	6210-2RS	50
240mm	4	10	17	6210-2RS	50
240mm	4	13	19	6210-2RS	50
240mm	5	6.5	12	6210-2RS	50
240mm	5	8	12	6210-2RS	50
240mm	5	10	17	6210-2RS	50
240mm	5	13	19	6210-2RS	50
240mm	6	6.5	12	6210-2RS	50
240mm	6	8	12	6210-2RS	50
240mm	6	10	17	6210-2RS	50
240mm	6	13	19	6210-2RS	50
240mm	7	6.5	12	6210-2RS	50
240mm	7	8	12	6210-2RS	50
240mm	7	10	17	6210-2RS	50
240mm	7	13	19	6210-2RS	50
240mm	8	6.5	12	6210-2RS	50
240mm	8	8	12	6210-2RS	50
240mm	8	10	17	6210-2RS	50
240mm	10	6.5	12	6210-2RS	50
240mm	10	8	12	6210-2RS	50

250mm Part Table

250mm Part Details
Size	Qty	Length	Width	Part No.	Weight
250mm	3	8	12	6209-2RS	45
250mm	4	8	12	6209-2RS	45
250mm	4	10	17	6209-2RS	45
250mm	5	8	12	6209-2RS	45
250mm	5	10	17	6209-2RS	45
250mm	6	6.5	12	6209-2RS	45
250mm	6	8	12	6209-2RS	45
250mm	6	10	17	6209-2RS	45
250mm	8	6.5	12	6209-2RS	45
250mm	8	8	12	6209-2RS	45
250mm	10	6.5	12	6209-2RS	45
250mm	10	8	12	6209-2RS	45

300mm Part Table

300mm Part Details
Size	Qty	Length	Width	Part No.	Weight
300mm	3	10	12	6210-2RS	50
300mm	3	13	17	6210-2RS	50
300mm	4	8	12	6210-2RS	50
300mm	4	10	17	6210-2RS	50
300mm	4	13	19	6210-2RS	50
300mm	5	8	12	6210-2RS	50
300mm	5	10	17	6210-2RS	50
300mm	5	13	19	6210-2RS	50
300mm	6	8	12	6210-2RS	50
300mm	6	10	17	6210-2RS	50
300mm	4	13	18	6212-2RS	60
300mm	8	8	12	6212-2RS	60
300mm	9	8	12	6212-2RS	60
300mm	10	8	12	6212-2RS	60
300mm	7	10	16	6212-2RS	60
300mm	8	10	16	6212-2RS	60
300mm	9	10	16	6212-2RS	60

320mm Part Table

320mm Part Details
Size	Qty	Length	Width	Part No.	Weight
320mm	3	13	19	6210-2RS	50
320mm	4	8	12	6210-2RS	50
320mm	4	10	17	6210-2RS	50
320mm	4	13	19	6210-2RS	50
320mm	5	8	12	6210-2RS	50
320mm	5	10	17	6210-2RS	50
320mm	5	13	19	6210-2RS	50
320mm	6	8	12	6210-2RS	50
320mm	6	10	17	6210-2RS	50
320mm	7	8	12	6210-2RS	50
320mm	8	8	12	6210-2RS	50
320mm	10	8	12	6210-2RS	50
320mm	12	8	12	6210-2RS	50

Table Example

METRO HYDRAULIC PULLY Data
Size	Qty	Length	Width	Part No.	Weight
327mm (METRO HYDRAULIC PULLY)	2	8	15	6010-2RS	50

360mm Part Table

360mm Part Details
Size	Qty	Length	Width	Part No.	Weight
360mm	4	10	17	6210-2RS	50
360mm	5	10	17	6210-2RS	50
360mm	6	10	17	6210-2RS	50

Groove Table - 400mm

Size	Groove Nos	Groove Size (mm)	Pitch (mm)	Bearing	Shaft (mm)
400mm	3	10	17	6210-2RS	50
	3	13	19	6210-2RS	50
	4	8	12	6210-2RS	50
	4	10	17	6210-2RS	50
	4	13	19	6210-2RS	50
	5	8	12	6210-2RS	50
	5	10	17	6210-2RS	50
	5	13	19	6210-2RS	50
	6	8	12	6210-2RS	50
	6	10	17	6210-2RS	50
	6	13	19	6210-2RS	50
	7	8	12	6210-2RS	50
	8	8	12	6210-2RS	50
	8	10	12	6210-2RS	50
	10	8	12	6210-2RS	50

500mm Part Table

500mm Part Details
Size	Qty	Length	Width	Part No.	Weight
500mm	4	13	18	6212-2RS	60
500mm	8	8	12	6212-2RS	60
500mm	9	8	12	6212-2RS	60
500mm	10	8	12	6212-2RS	60
500mm	7	10	16	6212-2RS	60
500mm	8	10	16	6212-2RS	60
500mm	9	10	16	6212-2RS	60

510mm Part Table

510mm Part Details
Size	Qty	Length	Width	Part No.	Weight
510mm	4	8	12	6210-2RS	50
510mm	4	10	12	6210-2RS	50

525mm Part Table

525mm Part Details
Size	Qty	Length	Width	Part No.	Weight
525mm	4	10	17	6210-2RS	50

Size	Groove Nos	Groove Size (mm)
200mm	1	6 & 8

300mm Groove Table

Size	Groove Nos	Groove Size (mm)
300mm	1	8
300mm	2	6 & 8

Pulley Description Table

Sr No	Pulley Description	PCD	Wire Dia	Groove
1	TRACTION SHEAVE(160PCDxØ6.5x4G)	160	6.5	4
2	TRACTION SHEAVE(160PCDxØ6.5x7G)	160	6.5	7

Pulley Data Table

Pulley Description	PCD	Wire Dia	Groove
TRACTION SHEAVE(200PCDxØ8x4G)	200	8	4
TRACTION SHEAVE(240XØ6.5X8G)	240	6.5	8
TRACTION SHEAVE(240PCDXØ6.5X10G)	240	6.5	10
TRACTION SHEAVE(240PCDxØ8x4G)	240	8	4

240mm Traction Sheave

240mm Traction Sheave Details
Sr. No.	Description	PCD (mm)	Hole Ø (mm)	No. of Holes
1	TRACTION SHEAVE (240XØ6.5X8G)	240	6.5	8
2	TRACTION SHEAVE (240PCDXØ6.5X10G)	240	6.5	10
3	TRACTION SHEAVE (240PCDxØ8x4G)	240	8	4

320 PCD Pulley Table

Pulley Description	PCD	Wire Dia	Groove
TRACTION SHEAVE(320PCDXØ8X4G)	320	8	4
TRACTION SHEAVE(320PCDXØ8X6G)	320	8	6
TRACTION SHEAVE(320PCDxØ8x8G)	320	8	8
TRACTION SHEAVE(320PCDxØ8X12G)	320	8	12

400 PCD Pulley Table

Pulley Description	PCD	Wire Dia	Groove
TRACTION SHEAVE(400PCDXØ8X4G)	400	8	4

Pulley Table

Sr No	Pulley Description
1	2G Diverter Sheave
2	3G Diverter Sheave
3	4G Diverter Sheave
4	5G Diverter Sheave

Pulley Table

Sr No	Pulley Description
1	Timing Belt Pulley

Pulley Table

Sr No	Pulley Description
1	V-Belt Pulley A-type
2	V-Belt Pulley B-type
